Part Number: 3584
Category: Electric Motors → Single-Phase Electric Motors → TEFC C-Face Motors
Type: M.M.R. TEFC Electric Motor – 2 HP 3450 RPM C-Face 5/8" Shaft with Switch, Cord & GFCI

The M.M.R. TEFC Electric Motor (Part #PCL3515M) is a genuine OEM 2 horsepower single-phase electric motor manufactured by Baldor Motors for commercial and industrial equipment requiring dependable high-speed performance. Featuring a Totally Enclosed Fan Cooled (TEFC) design, this motor operates at 3,450 RPM and is ideal for electric pressure washers, pumps, compressors, industrial machinery, and other continuous-duty applications.

Key Features & Benefits

• Genuine Baldor OEM electric motor
• Part Number: PCL3515M
• Heavy-duty TEFC (Totally Enclosed Fan Cooled) design
• 2 horsepower output
• Operates at 3,450 RPM
• Single-phase 115/230 VAC operation
• 56C C-Face mounting
• 5/8-inch keyed shaft
• Factory-wired with on/off switch
• Includes power cord and integrated GFCI protection
• Designed for continuous-duty operation
• Excellent for electric pressure washer applications
• OEM-quality construction for long service life

Technical Specifications

Part Number: PCL3515M

Manufacturer: Baldor Motors

Manufacturer Model Number: PCL3515M

Product Type: Single-Phase TEFC Electric Motor

Horsepower: 2 HP

Voltage: 115/230 VAC

Phase: Single Phase

Full Load Amps: 18A @ 115V / 9A @ 230V

Motor Type: TEFC (Totally Enclosed Fan Cooled)

Operating Speed: 3,450 RPM

Frame Size: 56C

Mounting Style: C-Face

Shaft Diameter: 5/8"

Weight: 46 lbs

Includes:

• Factory-installed On/Off Switch
• Power Cord
• Integrated GFCI Protection

OEM Replacement: Yes

Compatible Applications

Designed for use with compatible equipment including:

• Electric pressure washer systems
• Pressure washer pump packages
• Industrial pumps
• Air compressors
• Commercial cleaning equipment
• Industrial machinery
• Manufacturing equipment
• OEM equipment installations
• Motor replacement projects

Always verify voltage, frame size, shaft diameter, mounting style, horsepower, and rotation before ordering.

Function of the Electric Motor

The PCL3515M motor helps:

• Deliver reliable 2 HP power output
• Drive pressure washer pumps and industrial equipment
• Maintain consistent 3,450 RPM operating speed
• Provide dependable continuous-duty performance
• Improve equipment efficiency and reliability
• Offer enhanced electrical safety with integrated GFCI protection

Its TEFC enclosure protects internal motor components from dust, dirt, and moisture, making it well suited for demanding work environments.

Common Signs Replacement Is Needed

Replace the motor if you notice:

• Failure to start
• Overheating during operation
• Excessive vibration
• Bearing noise
• Reduced power output
• Electrical winding failure
• Damaged shaft
• Excessive current draw
• Frequent GFCI tripping caused by internal motor faults

Replacing a worn motor restores equipment performance while helping minimize costly downtime.

Installation & Service Notes

• Disconnect electrical power before installation or servicing.
• Verify compatibility with the 56C C-Face, 5/8-inch shaft, voltage, horsepower, and rotation requirements.
• Mount the motor securely using the appropriate C-Face hardware.
• Ensure proper shaft alignment with the driven pump or equipment.
• Connect the motor according to the supplied wiring instructions and local electrical codes.
• Test the integrated GFCI before operation to verify proper functionality.
• Verify correct motor rotation before placing the equipment into service.

Important: Proper shaft alignment and secure mounting help reduce vibration, extend bearing life, and maximize overall motor performance. Periodically test the GFCI to ensure continued electrical protection.

Maintenance Recommendations

• Keep the TEFC housing and cooling fins clean to maintain proper airflow.
• Inspect electrical connections, power cord, switch, and GFCI regularly.
• Monitor operating temperature and current draw during routine maintenance.
• Check shaft alignment periodically to minimize bearing and coupling wear.
• Lubricate bearings according to Baldor's recommended maintenance schedule, where applicable.
• Use only genuine OEM Baldor replacement parts to maintain optimum performance, reliability, and long service life.
