Kenmore KC76FDWJZ000 Overload Protector – Genuine OEM Replacement Vacuum Motor Overload Protector
Part Number: KC76FDWJZ000
Category: Vacuum Parts & Accessories → Vacuum Electrical Components → Motor Overload Protectors
Type: Kenmore KC76FDWJZ000 Overload Protector – Genuine OEM Replacement Vacuum Motor Overload Protector
The Kenmore KC76FDWJZ000 Overload Protector is a genuine OEM replacement motor protection device designed for compatible Kenmore upright vacuum cleaners. This overload protector helps safeguard the vacuum motor by interrupting electrical power when excessive current or overheating is detected, helping prevent motor damage caused by overload conditions. Manufactured to original equipment specifications, it provides a direct-fit replacement for a faulty or damaged overload protector, restoring the vacuum's original motor protection and dependable operation.
Key Features & Benefits
- Part Number: KC76FDWJZ000
- Genuine OEM Kenmore replacement part
- Replacement vacuum motor overload protector
- Helps protect the motor from overheating and excessive current
- Supports safe and reliable vacuum operation
- Helps prevent premature motor damage
- Precision-engineered electrical protection component
- Direct-fit OEM replacement
- Manufactured to original equipment specifications
Technical Specifications
Part Number: KC76FDWJZ000
Manufacturer: Kenmore
Product Type: Motor Overload Protector
OEM Part: Yes
Application: Vacuum Motor Protection System
Compatible Applications
The Kenmore KC76FDWJZ000 Overload Protector fits select:
- Kenmore 116.31150313 Elite Upright Vacuum
- Kenmore 116.31150312 Elite Upright Vacuum
- Kenmore 116.31140311 Upright Vacuum
- Kenmore 125.31150610 Elite Upright Vacuum
- Kenmore 116.31140310 Upright Vacuum
- Kenmore 125.31140610 Upright Vacuum
- Other compatible Kenmore vacuum models utilizing Part #KC76FDWJZ000
Always verify your vacuum model number and original part number before ordering to ensure proper compatibility.
Function of the Overload Protector
The Kenmore KC76FDWJZ000 Overload Protector serves as an important safety component within the vacuum's electrical system. It helps to:
- Protect the vacuum motor from overload conditions
- Interrupt electrical power when excessive heat or current is detected
- Help prevent permanent motor damage
- Support safe and dependable vacuum operation
- Restore the vacuum's original motor protection system
- Promote long-term motor reliability
Using a genuine OEM replacement overload protector helps ensure proper electrical protection, dependable performance, and long-term vacuum reliability.
Common Signs Replacement Is Needed
Replace the overload protector if you notice:
- Vacuum fails to power on despite a verified power source
- Intermittent motor operation
- Motor shuts off unexpectedly without an airflow blockage
- Overload protector no longer resets properly
- Visible heat damage or corrosion
- Electrical testing confirms a failed overload protector
Because similar symptoms may also be caused by a faulty motor, power switch, wiring, or power cord, inspect the complete electrical system before replacing the overload protector.
Installation & Service Notes
Disconnect the vacuum from the power source before performing any repairs.
Access the motor compartment according to the manufacturer's service instructions. Remove the existing KC76FDWJZ000 Overload Protector and inspect the surrounding wiring, terminals, and motor assembly for signs of overheating or damage. Install the replacement overload protector in the original position, ensuring all electrical connections are secure before reassembling the vacuum. Test the vacuum to confirm normal operation before returning it to service.
Important: Always verify your vacuum model number and original part number before ordering. Use genuine OEM Kenmore replacement electrical components to ensure proper fit, reliable motor protection, and long-term vacuum performance.
Maintenance Recommendations
- Clean or replace filters regularly to maintain proper airflow.
- Remove clogs from the hose, wand, and nozzle promptly.
- Empty the dust container or replace vacuum bags before they become overfilled.
- Inspect electrical components during routine maintenance.
- Avoid operating the vacuum with blocked airflow, which can cause motor overheating.
- Use genuine OEM replacement parts to maintain factory electrical protection, reliable motor performance, and long-term vacuum operation.
