Husqvarna 530016240 Belleville Washer – Genuine OEM Replacement Equipment Hardware

Part Number: 530016240
Category: Outdoor Power Equipment Hardware, Fasteners & Washers
Type: Belleville Washer – Genuine OEM Replacement Equipment Hardware

The Husqvarna 530016240 Belleville Washer is a genuine OEM replacement hardware component designed for select Husqvarna outdoor power equipment and compatible applications. A Belleville washer uses a slightly conical spring-style profile to provide controlled axial force within the applicable mechanical or fastener assembly.

Product Specifications

• Part Number: 530016240
• Manufacturer: Husqvarna
• Product Type: Belleville Washer
• OEM Description: Washer, Belleville
• Alternate Description: Conical Spring Washer / Disc Spring Washer
• Component Type: Equipment Hardware / Spring Washer
• Washer Style: Belleville / Conical
• Function: Provides Axial Spring Force & Factory-Specified Tension
• System: Model & Assembly Dependent
• Application: Outdoor Power Equipment
• Compatible Brand: Husqvarna
• Additional Applications: Select Poulan / Poulan Pro / Craftsman Equipment
• Component Location: Model & Assembly Dependent
• Replacement Type: Direct OEM Replacement
• OEM Status: Genuine Husqvarna OEM Part
• Condition: New
• Quantity: 1 Belleville Washer
• Part Number Reference: 530016240

Features & Benefits

• Genuine Husqvarna OEM replacement hardware
• Factory-designated Belleville Washer
• Conical spring-style washer design
• Designed for compatible Husqvarna equipment
• Provides controlled axial spring force
• Helps maintain factory-specified tension within the applicable assembly
• Compensates for limited movement or dimensional variation where specified
• Helps maintain proper component positioning
• Can help reduce unwanted loosening in the intended application
• Works with associated OEM fasteners and mechanical components
• Manufactured to original equipment specifications
• Provides factory-style dimensions, profile, and fit
• Suitable for equipment maintenance, repair, and restoration
• Ideal replacement for flattened, cracked, distorted, corroded, worn, damaged, or missing washers
• Direct replacement for equipment requiring 530016240
• Genuine OEM component rather than an unspecified universal washer

Applications

The Husqvarna 530016240 Belleville Washer is intended for select Husqvarna-family equipment specifically designed to use this OEM spring washer.

Applications may include:

• Husqvarna outdoor power equipment
• Poulan outdoor power equipment
• Poulan Pro equipment
• Select Craftsman equipment
• Chainsaw assemblies
• Trimmer and brushcutter assemblies
• Blower assemblies
• Small-engine equipment
• Clutch or drive assemblies where specified
• Shaft and fastener assemblies
• Mechanical retaining systems
• Equipment repair and restoration
• OEM replacement applications requiring 530016240

Because the exact installation location can vary between equipment models, compatibility should always be confirmed using the complete model and product number.

Important Notes

• Verify compatibility with your specific equipment model, product number, serial number, assembly configuration, and production revision before ordering.
• Husqvarna identifies 530016240 as a Belleville Washer.
• Match part number 530016240 directly with the number shown in your equipment's illustrated parts diagram or OEM documentation.
• A Belleville washer is not the same as a conventional flat washer. Its conical shape is designed to provide spring force when compressed.
• Do not substitute a standard flat washer, split lock washer, wave washer, thrust washer, shim, or spacer unless specifically approved for the application.
• Belleville washers can differ in inside diameter, outside diameter, thickness, cone height, material, hardness, spring rate, and load capacity.
• Do not select a replacement based solely on approximate diameter or visual similarity.
• The orientation of a Belleville washer can be important. Install 530016240 in the same direction and sequence specified in the applicable OEM parts diagram or service procedure.
• If multiple Belleville washers are used together in an assembly, their orientation may affect the resulting spring force and travel.
• Do not flatten, bend, reshape, grind, or otherwise modify the washer before installation.
• Inspect the associated fastener, shaft, clutch component, bearing, spacer, retainer, and mounting surfaces when replacing the washer.
• If the original washer has become completely flat, cracked, or severely distorted, inspect surrounding components for excessive load, incorrect assembly, overheating, or abnormal wear.
• Replace damaged or excessively worn associated hardware as necessary.
• Clean the mating surfaces before installing the replacement washer.
• Install all washers, spacers, retainers, and related hardware in the correct factory sequence.
• Tighten associated fasteners according to the manufacturer's specifications.
• Excessive tightening can permanently flatten or damage a Belleville washer and may alter the intended clamping force.
• After installation, verify that the associated assembly is correctly retained and operates without excessive play, binding, or interference.
• Shut off the equipment, allow all moving components to stop, disconnect the applicable power source, and follow manufacturer service procedures before performing repairs.
• This listing is for one Husqvarna 530016240 Belleville Washer only unless otherwise specified. Bolts, nuts, shafts, bearings, spacers, clutch components, and other associated hardware are sold separately.
• Match part number 530016240 with your equipment's illustrated parts diagram or OEM documentation before ordering to ensure proper fitment.
