Husqvarna 514382501 Seal – Genuine OEM Replacement Equipment Seal

Part Number: 514382501
Category: Trimmer & Brush Cutter Gearbox Parts
Type: Oil Seal – Genuine OEM Replacement Equipment Seal

The Husqvarna 514382501 Seal is a genuine OEM replacement sealing component designed for select Husqvarna and RedMax trimmers, brush cutters, and edgers. The seal is used within the applicable bevel gear / gearcase assembly, where it helps retain lubrication and protect internal components from contamination.

Product Specifications

• Part Number: 514382501
• Manufacturer: Husqvarna
• Product Type: Oil Seal / Equipment Seal
• Description: Seal
• Reference: Z356513130
• Dimensions: Approximately 15 x 26 x 3.5 mm
• System: Bevel Gear / Gearcase Assembly
• Application: Trimmer, Brush Cutter & Edger
• Compatible Brands: Husqvarna & RedMax
• OEM Status: Genuine Husqvarna OEM Part
• Condition: New
• UPC: 193028519576
• Quantity: 1 Seal

Features & Benefits

• Genuine Husqvarna OEM replacement seal
• Designed for compatible gearcase and bevel gear assemblies
• Helps retain lubricant within the applicable gear assembly
• Helps prevent dirt and debris from reaching internal components
• Approximately 15 x 26 x 3.5 mm
• Suitable for replacing worn, hardened, cracked, damaged, or leaking seals
• Designed for factory-correct fit and configuration
• Compatible with select Husqvarna and RedMax equipment
• Direct replacement for equipment requiring part number 514382501

Applications

Confirmed applications include:

• Husqvarna 426LST Trimmer
• RedMax BC-EX3 Edger
• RedMax BC220DL
• RedMax BC221DL
• RedMax BC2601DLS
• RedMax BCX2600DL
• RedMax BCX2600S
• RedMax BCZ2450S
• RedMax BCZ2450T
• RedMax BCZ2460S
• RedMax BCZ2460TS
• RedMax BCZ2500 Series
• RedMax BCZ2650 Series
• RedMax BCZ275G-DC
• RedMax BCZ3000 / BCZ3001 Series
• RedMax BCZ3050 Series
• Select additional compatible Husqvarna and RedMax equipment

Important Notes

• Verify compatibility with your specific equipment model, product number, and production configuration before ordering.
• Husqvarna replacement-parts catalogs identify 514382501 as “Seal.”
• Detailed parts documentation identifies the seal as Z356513130 and specifies dimensions of 15 x 26 x 3.5 mm.
• 514382501 replaces previous part numbers 5143825-01, 5211970-01, and 521197001.
• The previous 521197001 part is identified as an oil seal and has been superseded by 514382501.
• On applicable RedMax brush cutters, 514382501 is installed within the bevel gear assembly alongside the holder, cover, snap rings, and related gearbox hardware.
• This listing is for one seal only unless otherwise specified. Gearcases, bevel gears, bearings, holders, covers, snap rings, shafts, fasteners, and other components are sold separately.
• Inspect the mating surfaces, bearings, shaft, gearcase, and surrounding components when replacing the seal. Replace worn or damaged related components as necessary to help prevent premature seal failure.
• Match part number 514382501 with your equipment's illustrated parts diagram before ordering to ensure proper fitment.
