Husqvarna 505133601 Cup – Genuine OEM Replacement Equipment Cup

Part Number: 505133601
Category: Chainsaw Engine, Crankshaft & Bearing Components
Type: Crankshaft Cup – Genuine OEM Replacement Engine Component

The Husqvarna 505133601 Cup is a genuine OEM replacement engine component designed for select Husqvarna professional chainsaws, including documented 560 XP and 562 XP series applications. Husqvarna parts documentation identifies 505133601 as a Cup Assembly used within the crankshaft assembly of compatible chainsaws.

Product Specifications

• Part Number: 505133601
• Manufacturer: Husqvarna
• Product Type: Cup
• OEM Description: Cup / Cup Assembly
• Alternate Description: Crankshaft Cup / Starter Cup / Drive Cup
• Component Type: Engine / Crankshaft Component
• System: Crankshaft / Starting Assembly
• Application: Chainsaw
• Compatible Brand: Husqvarna
• Documented Models: 560 XP / 560 XPG / 562 XP / 562 XPG
• Component Location: Crankshaft / Flywheel & Starting Interface
• Material: Steel
• Approximate Dimensions: 62 mm × 62 mm × 12 mm
• Approximate Weight: 45 g
• Replacement Type: Direct OEM Replacement
• OEM Status: Genuine Husqvarna OEM Part
• Condition: New
• Quantity: 1 Cup
• Part Number Reference: 505133601
• Alternate Number Format: 505 13 36-01

Parts references list the component at approximately 62 mm wide, 62 mm long, 12 mm high, and 45 g.

Features & Benefits

• Genuine Husqvarna OEM replacement component
• Factory-designated Cup / Cup Assembly
• Designed for select Husqvarna professional chainsaws
• Used within the applicable crankshaft assembly
• Supports the crankshaft and starting interface
• Provides a reliable drive surface for starter engagement
• Helps maintain proper alignment within the applicable engine assembly
• Durable steel construction
• Manufactured to match original equipment requirements
• Factory-style dimensions and fit
• Designed for direct installation on compatible chainsaws
• Helps restore proper starting engagement when replacing a worn component
• Suitable for engine maintenance and crankshaft repairs
• Ideal replacement for worn, distorted, damaged, or missing cups
• Direct replacement for equipment requiring 505133601
• Genuine OEM component rather than an unspecified universal replacement

Documented Applications

The Husqvarna 505133601 Cup is documented for select professional chainsaw models, including:

• Husqvarna 560 XP
• Husqvarna 560 XPG
• Husqvarna 562 XP
• Husqvarna 562 XPG
• Select compatible Jonsered applications
• Chainsaw crankshaft assemblies
• Starter / crankshaft interface assemblies
• Engine rebuilding applications
• OEM replacement applications requiring 505133601

Parts catalogs specifically list 505133601 for the Husqvarna 560XP/XPG and 562XP/XPG, while Husqvarna parts documentation shows the cup within the 562 XP crankshaft assembly.

Crankshaft Assembly Function

On documented Husqvarna 562 XP applications, 505133601 appears directly within the crankshaft parts breakdown alongside the crankshaft assembly, ball bearings, needle bearing, and radial seals. Husqvarna specifies two cup assemblies in the applicable crankshaft configuration.

This makes the component part of the engine's internal crankshaft-related assembly rather than a generic external equipment cup.

Important Notes

• Verify compatibility with your specific Husqvarna chainsaw model, product number, serial number, engine configuration, and production revision before ordering.
• Husqvarna documentation identifies 505133601 as a Cup Assembly within applicable crankshaft assemblies.
• Match part number 505133601 directly with the number shown in your chainsaw's illustrated parts diagram.
• The alternate formatted part number may appear as 505 13 36-01.
• This component is documented for the 560 XP and 562 XP family of chainsaws.
• Do not confuse this part with a beverage cup, dust cup, debris cup, bearing race, generic spacer, or unrelated equipment component.
• Repair Clinic categorizes 505133601 as a genuine OEM chainsaw bearing/cup component.
• Husqvarna documentation indicates that some applicable crankshaft configurations use a quantity of two 505133601 cups.
• This listing is for one cup unless otherwise specified.
• Do not assume that the crankshaft, bearings, radial seals, needle bearing, flywheel, starter assembly, or other engine components are included.
• Inspect associated crankshaft components, bearings, seals, and mating surfaces when replacing the cup.
• If the original cup is damaged or abnormally worn, inspect the surrounding assembly for misalignment, bearing wear, excessive vibration, or corresponding damage.
• Do not attempt to reshape or reuse a severely distorted component.
• Clean the installation area before fitting the replacement cup.
• Install 505133601 in the same factory location and orientation as the original component.
• Follow the applicable Husqvarna service documentation when disassembling or rebuilding crankshaft-related engine components.
• Ensure associated bearings, seals, and other components are correctly seated during reassembly.
• Verify that the crankshaft rotates properly after assembly and before returning the chainsaw to service.
• Shut off the chainsaw, allow the engine to cool completely, disconnect the spark plug, and drain fuel where required before performing major engine repairs.
• This listing is for one Husqvarna 505133601 Cup only unless otherwise specified. Crankshafts, bearings, seals, flywheels, starter components, fasteners, and other engine components are sold separately.
• Match part number 505133601 with your equipment's illustrated parts diagram or OEM documentation before ordering to ensure proper fitment.
