Husqvarna 501630601 Sleeve – Genuine OEM Replacement Equipment Sleeve

Part Number: 501630601
Category: Chainsaw Recoil Starter, Starter Rope & Housing Components
Type: Starter Cord Sleeve – Genuine OEM Replacement Starter Component

The Husqvarna 501630601 Sleeve is a genuine OEM replacement component designed for select Husqvarna chainsaws and compatible outdoor power equipment. Husqvarna's official illustrated parts lists identify 501630601 as a Sleeve located within the starter assembly alongside components such as the starter housing, starter pulley, spring cassette, starter rope, and starter handle.

Product Specifications

• Part Number: 501630601
• Manufacturer: Husqvarna
• Product Type: Sleeve
• OEM Description: Sleeve
• Alternate Description: Starter Cord Sleeve / Starter Rope Sleeve
• Component Type: Recoil Starter / Starter Rope Component
• Function: Supports & Guides the Starter Cord Within the Starter Assembly
• System: Recoil Starter System
• Application: Chainsaw / Outdoor Power Equipment
• Compatible Brand: Husqvarna
• Additional Applications: Select Jonsered / Poulan / RedMax Equipment
• Component Location: Recoil Starter Assembly
• Associated Components: Starter Rope / Starter Housing / Starter Pulley / Starter Handle
• Replacement Type: Direct OEM Replacement
• OEM Status: Genuine Husqvarna OEM Part
• Condition: New
• Quantity: 1 Sleeve
• Part Number Reference: 501630601

Husqvarna's official parts documentation confirms the 501630601 Sleeve as a component of the recoil starter assembly on applicable equipment.

Features & Benefits

• Genuine Husqvarna OEM replacement component
• Factory-designated Sleeve
• Used within compatible recoil starter assemblies
• Commonly identified as a starter cord sleeve
• Helps guide and support the starter rope
• Provides a defined contact point for the starter cord
• Helps maintain proper starter-rope routing
• Supports smooth movement of the starter rope during starting
• Works with the applicable starter housing, rope, pulley, and handle
• Manufactured to original equipment requirements
• Provides factory-style dimensions and fit
• Helps restore a worn or incomplete recoil starter assembly
• Suitable for chainsaw starter repair and rebuilding
• Ideal replacement for worn, cracked, grooved, distorted, damaged, or missing sleeves
• Direct replacement for equipment requiring 501630601
• Genuine OEM component rather than an unspecified universal sleeve

Applications

The Husqvarna 501630601 Sleeve is documented for numerous Husqvarna chainsaw and power-equipment applications. Husqvarna's official parts diagrams show it within the starter assemblies of models including the 55 Rancher EPA and 3120.

Additional documented applications include select:

• Husqvarna 40
• Husqvarna 49
• Husqvarna 51
• Husqvarna 55
• Husqvarna 55 Rancher / 55 Rancher EPA
• Husqvarna 61
• Husqvarna 268 Special
• Husqvarna 272 XP
• Husqvarna 3120
• Husqvarna 340 EPA
• Husqvarna 357 XP
• Husqvarna 359
• Husqvarna 362
• Husqvarna 390
• Husqvarna 394 XP
• Select Jonsered equipment
• Select Poulan equipment
• Select RedMax equipment

Parts references also cross-list the component with models such as the 268 Special, 272 XP, 3120, 340 EPA, 357 XP, 359, 362, 390, and 394 XP.

Recoil Starter Function

On compatible equipment, the 501630601 Sleeve is positioned within the recoil starter system. The starter rope repeatedly moves through the assembly each time the operator pulls the starter handle.

The sleeve helps provide the intended guide and contact area for the starter cord. Maintaining the correct sleeve can help prevent the starter rope from contacting an improperly shaped or damaged surface within the starter housing.

Husqvarna's official 55 Rancher parts breakdown places 501630601 in the same starter assembly as the starter pulley, starter housing, spring cassette, starter rope, and starter handle.

Important Notes

• Verify compatibility with your specific Husqvarna model, product number, serial number, starter configuration, and production revision before ordering.
• Husqvarna officially identifies 501630601 as a Sleeve.
• Parts references further identify the component as a starter cord sleeve.
• Match part number 501630601 directly with the number shown in your equipment's illustrated parts diagram or OEM documentation.
• This component is associated with the recoil starter assembly and should not be confused with an engine shaft sleeve, bearing sleeve, spacer, bushing, or cylinder component.
• Do not assume that the starter rope, starter handle, pulley, recoil spring, spring cassette, or starter housing is included.
• Inspect the starter rope when replacing the sleeve. Replace rope that is frayed, flattened, cut, melted, excessively worn, or otherwise damaged.
• Inspect the starter housing around the sleeve mounting location for cracking, distortion, sharp edges, or excessive wear.
• Check the starter pulley for cracking, excessive groove wear, or damage that could contribute to premature starter-rope failure.
• Inspect the recoil spring or spring cassette if the starter rope does not retract correctly.
• Do not substitute a generic sleeve based solely on approximate dimensions.
• Sleeve inside diameter, outside diameter, length, material, and starter-housing fit can vary between equipment models.
• Install 501630601 in the same factory location and orientation as the original component.
• Make sure the starter rope is routed correctly through the sleeve and starter assembly.
• Verify that the starter rope pulls and retracts smoothly before operating the equipment.
• Avoid allowing the starter handle to snap violently back against the starter housing after pulling.
• Recoil starter springs can store significant mechanical energy. Use appropriate care when disassembling the starter mechanism.
• Shut off the equipment, allow the engine to cool, disconnect the spark plug, and follow Husqvarna service procedures before performing starter repairs.
• This listing is for one Husqvarna 501630601 Sleeve only unless otherwise specified. Starter ropes, handles, pulleys, spring cassettes, housings, screws, and other recoil-starter components are sold separately.
• Match part number 501630601 with your equipment's illustrated parts diagram or OEM documentation before ordering to ensure proper fitment.
