BE Power 3,500 PSI 8.5 GPM Hot Water Pressure Washer – Honda GX690 Engine, AR Pump (HW3524HA12V)

Key Specifications

• Pressure: 3,500 PSI

• Flow Rate: 8.5 GPM

• Engine: Honda GX690 V-Twin (688cc) with Electric Start

• Battery: 55AH Marine-grade AGM included

• Pump: AR (Annovi Reverberi) Triplex Pump – reinforced body, brass manifold, ceramic plungers

• Drive Type: Belt-driven for extended life and smoother operation

• Burner: 12V Beckett diesel-fired burner

• BTU Output: 330,000

• Max Temperature: 200°F / 93°C

• Unloader: External for precise pressure regulation & pump cooling

• Frame: 1.5" OD Powder-coated steel roll cage (truck/trailer mount ready)

• Accessories: 50-ft steel-braided hose, 47" insulated gun/wand, 5 quick-connect spray nozzles

• Oil Drain Hoses: Installed on engine and pump for clean, easy servicing

• Mounting: Truck/trailer compatible with integrated brackets and lift point

• Weight: 975 lbs

• Dimensions (L x W x H): 48" x 46" x 51"

Overview

The HW3524HA12V is BE Power Equipment’s extreme-flow, high-temperature industrial washer engineered for professionals who need speed, power, and reliability. Delivering 3,500 PSI at 8.5 GPM, this unit combines the Honda GX690 V-Twin engine, a belt-driven AR triplex pump, and a 12V diesel-fired Beckett burner for a powerhouse cleaning solution that thrives in demanding environments.

Whether mounted on a service truck, trailer, or skid, this unit is purpose-built for industries where downtime isn’t an option.

Core Features

 Heat + Flow + Pressure

• Produces 200°F hot water for cutting grease, oil, and contaminants.

• High volume output (8.5 GPM) speeds up rinsing and surface coverage.

• Adjustable thermostat with burner rocker switch for hot/cold flexibility.

 Honda GX690 Engine

• Commercial-grade V-Twin, 688cc with electric start.

• Low fuel consumption, smooth operation, and long service life.

• AGM battery included for reliable ignition in the field.

 AR Industrial Triplex Pump

• Forged brass manifold + ceramic plungers for hot water durability.

• Stainless steel check valves for precise pressure control.

• Thermal relief valve to protect against overheating.

• Belt-driven for reduced wear and extended lifespan.

 Rugged Mobile Frame

• Powder-coated steel roll cage with built-in lift point.

• 13” flat-free tires for mobility or remove wheels for truck/trailer mounting.

• Compact footprint designed for permanent wash rigs and service trailers.

 Service-Friendly

• Oil drain hoses on engine and pump for quick, mess-free oil changes.

• Open frame design for easy access and maintenance.

• External unloader extends pump life and simplifies adjustments.

 Commercial Accessories

• 50-ft high-pressure steel-braided hose.

• 47” insulated spray wand + gun with safety lock.

• 5 quick-connect nozzles (0°, 15°, 25°, 40°, Soap).

Applications

The HW3524HA12V is designed for high-output professionals who need fast, effective hot water cleaning.

Perfect for:

• Heavy equipment yards and fleet washing

• Construction & demolition site cleanup

• Industrial facility and plant sanitation

• Agricultural & livestock operations

• Concrete surface prep and restoration

• Oilfield and municipal service work

Shipping Info

• Weight: 975 lbs

• Dimensions (L x W x H): 48" x 46" x 51"

• Units per Pallet: 1

• Note: All units are factory-tested and may contain residual oil or fuel odor.

HW3524HA12V — Built for pros who demand more flow, more heat, and maximum durability. With a Honda GX690 engine, AR triplex pump, and Beckett burner system, it’s the ultimate heavy-duty hot water washer for commercial cleaning power on the move.
