BE Power 3,500 PSI 5.2 GPM Hot Water Skid Pressure Washer – Honda GX690 Engine, General TS2021 Pump (Z5535GPBDH)

Key Specifications

• Pressure: 3,500 PSI

• Flow Rate: 5.2 GPM

• Engine: Honda GX690, 688cc, V-Twin, Electric Start

• Pump: General TS2021 Triplex, Belt-Drive

• Drive Type: Belt-driven (reduced vibration & extended pump life)

• Unloader: External (better cooling & long-term serviceability)

• Burner: Diesel-fired 12V Beckett, 350,000 BTU

• Max Temperature Rise: Up to 165°F (89°C)

• Heating Coil: Schedule 80 carbon steel wrapped in stainless steel

• Frame: Heavy-duty powder-coated steel skid with stainless control panel & enclosed belt guard

• Accessories Included:

  • 50’ high-pressure twin-wire braided hose

  • 48” insulated spray gun & wand with quick-connect fittings

  • 2 quick-connect nozzles (15°, 25°)

• Shipping Weight: 730 lbs

• Shipping Dimensions (LxWxH): 42” x 36.5” x 54”

Overview

The BE Power Z5535GPBDH is built for industrial strength cleaning in the toughest environments. Delivering 3,500 PSI at 5.2 GPM, it combines a Honda GX690 commercial-grade V-Twin engine, a belt-driven General TS2021 triplex pump, and a 12V diesel-fired Beckett burner to provide both raw pressure and high heat—essential for heavy grease, oil, and industrial grime removal.

Its rugged steel skid frame with powder coating and stainless control panel makes it ideal for truck or trailer mounting, while the professional-grade components ensure long service life, reduced downtime, and maximum cleaning efficiency.

Core Features

 Hot Water Cleaning

• Diesel-fired 12V Beckett burner produces up to 350,000 BTU/hour.

• Water temperatures up to 165°F (89°C) for cutting through grease, oil, and heavy buildup.

• Schedule 80 carbon steel heating coil wrapped in stainless steel for durability and corrosion resistance.

 Honda GX690 Engine

• 688cc OHV V-Twin delivers commercial-grade reliability.

• Electric start with 55AH AGM marine battery included.

• Designed for long runtimes, smooth torque, and reduced fuel consumption.

 General TS2021 Triplex Pump

• Belt-driven system lowers RPM and vibration, extending pump life.

• Forged brass manifold and solid ceramic plungers for hot water and chemical resistance.

• Stainless steel check valves for precision and longevity.

• External unloader valve for enhanced cooling and performance.

 Rugged Skid Frame

• Heavy-duty steel frame with powder-coated finish resists corrosion.

• Stainless steel control panel with diagnostic LED lights.

• Enclosed belt guard for safety.

• Truck/trailer mount ready for mobile operations.

 Included Accessories

• 50’ high-pressure hose (twin-wire braided).

• 48” insulated commercial spray gun & wand.

• 2 quick-connect nozzles (15° & 25°).

• All accessories built for high-heat, high-PSI use.

Applications

The Z5535GPBDH is engineered for industrial and commercial cleaning, making it ideal for:

• Industrial facility maintenance

• Heavy equipment & fleet washing

• Food processing plants & commercial kitchens

• Municipal & government building cleanup

• Construction & demolition site washing

• Agricultural & livestock sanitation

Shipping

• Weight: 730 lbs

• Dimensions (LxWxH): 42” x 36.5” x 54”

• Units are factory-tested and may contain residual oil or fuel.

Z5535GPBDH — 3,500 PSI @ 5.2 GPM, Honda GX690 engine, General TS2021 belt-drive triplex pump, diesel-fired hot water up to 165°F. The heavy-duty hot water skid pressure washer built to endure the toughest jobs and perform every time.
